Project Overview
Airmaster required mechanical services drafting and coordination support for the HWL Ebsworth project, involving upgrades and coordination within a commercial office environment. The project focused on supporting mechanical service layouts, documenting existing conditions, and preparing accurate drawings to assist installation and coordination across building services.
Deliverables
- Mechanical services layout drawings
- HVAC coordination documentation
- Existing-condition verification drawings
- Service routing and equipment coordination plans
- Mechanical drafting support for project execution
The Challenge
- Working within limited access and project timelines
- Ensuring accurate documentation for installation and contractor coordination
- Minimising clashes, rework, and site disruptions during execution
Before / After Transformation
Key Features
- Feature 1
- Feature 2
- Feature 3
- Feature 4
- Feature 5
Software Used
- AutoCAD
- Revit
- Navisworks
Output Formats
- CAD drawings
- PDF drawing packages
- Mechanical coordination documentation
- HVAC layouts
- As-built records
